Vacuum Insulation Panels (VIP) Manufacturer | 1.5 mW/(m·K)

Name: Vacuum Insulation Panels (VIP)
Brand: Supertech
SKU: ST-VIP

Key Facts

Thermal conductivity: as low as 1.5 mW/(m·K) at center of panel

Up to 10× the R-value of conventional insulation at equal thickness

Thickness 6–25 mm standard; custom shapes, holes and grooves supported

Fiberglass or fumed silica core — non-combustible, ODS-free

In-house barrier film and getter production for stable long-term vacuum

A vacuum insulation panel (VIP) is a high-performance thermal insulation element consisting of a micro-porous core board that is evacuated and sealed inside a multi-layer gas-barrier envelope. By removing the air, gas-phase conduction and convection are almost eliminated, giving VIPs a thermal conductivity of 1.5–3.0 mW/(m·K) — roughly 5 to 10 times better than polyurethane foam and up to 10 times better than EPS or mineral wool.

Supertech produces the complete VIP value chain in-house — core material, barrier film, getter and panel lamination — which is why leading refrigerator brands, cold-chain packaging companies and construction suppliers source panels from our Fujian manufacturing center.

Why specify Supertech VIPs

Full vertical integration

Core board, high-barrier film, getter and lamination are all produced in-house, so panel quality and aging behaviour are controlled end-to-end instead of assembled from third-party components.

Barrier film engineered per application

Choose from metallized PET (VMPET V1/V3), transparent SiOx (PSI), aluminum laminate (V4), aluminum-free low-thermal-bridge film (V5) or nano barrier film, matched to service life and edge thermal-bridge requirements.

Custom fabrication

Panels are supplied cut-to-size with optional holes, grooves, chamfers and pre-applied facings for appliance cabinets, door panels, cold-room modules and prefabricated building elements.

Proven at appliance scale

Millions of panels shipped annually into high-end refrigerators and freezers, where a 10–20 mm VIP replaces 50–100 mm of PU foam and increases usable interior volume by up to 20%.

Technical Specifications

Vacuum insulation panel — typical technical data
Property	Value
Thermal conductivity (center of panel)	1.5–3.0 mW/(m·K) at 25 °C, depending on core and film class
Insulation performance vs. PU foam	≈ 5–10× at equal thickness
Core material	Centrifugal glass fiber board or fumed silica board
Barrier film options	VMPET V1 / V3, SiOx (PSI), aluminum laminate (V4), aluminum-free (V5), nano barrier film
Getter	Built-in multi-functional getter (in-house production) for gas and moisture adsorption
Standard thickness	6 / 8 / 10 / 12 / 15 / 20 / 25 mm (custom up to 50 mm)
Dimensions	Custom cut-to-size; die-cut shapes, holes and grooves available
Service temperature	−70 °C to +80 °C standard; high-temperature series −196 °C to +800 °C
Fire behaviour of core	Inorganic, non-combustible (Class A core material)
Environmental profile	No ODS / CFC / HCFC; recyclable inorganic core

Frequently Asked Questions

What is the thermal conductivity of a vacuum insulation panel?

Supertech VIPs achieve a center-of-panel thermal conductivity of 1.5–3.0 mW/(m·K) at 25 °C depending on core material and barrier film class. For comparison, polyurethane foam is typically 20–25 mW/(m·K) and EPS 33–38 mW/(m·K), so a VIP insulates roughly 5–10 times better at the same thickness.

How long do vacuum insulation panels last?

Service life depends on the barrier film and operating conditions. Appliance-grade panels are typically designed for 10–15 years, while panels with high-barrier laminate films used in construction are designed for 25 years or more. A built-in getter continuously adsorbs residual gas and moisture to keep the internal vacuum stable.

Can VIPs be cut on site?

No. Cutting the envelope destroys the vacuum and the panel reverts to the conductivity of its core (still a usable ~20 mW/(m·K) for fumed silica, but far from vacuum performance). Panels are therefore supplied cut-to-size from the factory, and layouts are engineered with matching filler panels for site tolerances.

What is the minimum order quantity and lead time?

MOQ and lead time depend on panel size and film selection. Standard appliance sizes ship from stock programs; custom sizes typically run 2–4 weeks after drawing approval. Send your drawings for a same-week quotation.
